Mercury 16 Port 48V POE Power Supply Full Gigabit Monitoring Switch
- It provides 16 10/100/1000M adaptive RJ45 ports, of which ports 1-14 are PoE ports, and ports 15 and 16 are uplink ports;
- It provides an ultra-distance mode switch and a VLAN isolation mode switch;
- It provides 8 priority ports, and data on the priority ports is transmitted first;
- It provides 6 ultra-distance ports, and the ultra-distance ports can transmit up to 260m after the ultra-distance mode is turned on;
- It supports the IEEE 802.3af/at standard, automatically detects and identifies the powered devices (PD) that comply with the IEEE 802.3af/at standard and supplies power to them.
- The power output power is 128W, and the single-port PoE power can reach 30W;
intelligent power management, if the power of the powered device exceeds the limit, the system starts the PoE port priority mechanism and cuts off the power supply of the port with low priority. - Each port supports MDI/MDIX automatic flipping and auto-negotiation;
- It supports IEEE 802.3x full-duplex flow control and Backpressure half-duplex flow control;
- It can be mounted on a rack;
- It is plug-and-play, no configuration required, simple and convenient.
| Web Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at | |
| port | 16 10/100/1000Mbps RJ45 ports, ports 1 to 14 support PoE function | |
| Indicator Lights | Each Gigabit port has a dual-color indicator light Each device has 1 Power and PoE Max indicator light | |
| Network media | 10BASE-T: Category 3, 4, 5 unshielded twisted pair 100BASE-TX: Category 5 and above unshielded twisted pair 1000BASE-T: Category 5e and above unshielded twisted pair | |
| Mode switch | Ultra-distance mode switch: When turned on, ports 9 to 14 work at a rate of 10Mbps, and the maximum transmission distance is 260m VLAN isolation switch: After it is turned on, ports 1 to 14 are isolated from each other and can only communicate with the Uplink port | |
| performance | Store and Forward Support 16K MAC address table depth | |
| Usage Environment | Working temperature: 0℃～40℃ Storage temperature: -40℃～70℃ Working humidity: 10%~90% RH non-condensing Storage humidity: 5%~90% RH non-condensing | |
| power supply | Built-in power supply, maximum output power 128W | |
| Dimensions (L*W*H) | 294mm*180mm*44mm | |
