Tp-Link AX5000 WIFI7 2.5G Port Dual Band Ceiling Access Point
- Buy 6 for ₹14,018.40 ₹11,880.00 each and save 10%
Quick Overview Hardware specifications
| Installation | - Ceiling/wall installation
|
| size | - Φ235×43.3mm(excluding mounting parts)
|
| wireless | - 2.4GHz band: 688 Mbps
- 5GHz band: 4323 Mbps
|
| port | - 1 10/100/1000/2500M RJ45 port
- 1 DC port
|
| Indicator Lights | |
| Button | - 1 Reset button
- 1 FAT/FIT mode toggle switch
- 1 easy-to-expand button
|
| Power supply mode | - 802.3at standard PoE power supply
- 12V/1.5A DC power supply
|
| Power consumption | - PoE power supply maximum power consumption 17.2W
- PoE power supply standby power consumption 5.9W
|
| manage | - FIT AP mode: managed by TP-LINK wireless controller (AC)
- FAT AP mode: independent web page management
- TP-LINK commercial network cloud platform centralized management
|
| Usage Environment | - Working temperature: 0℃～40℃
- Working humidity: 10%～90%RH non-condensing
- Storage temperature: -40℃～70℃
- Storage humidity: 5%~90%RH non-condensing
|
Software Specifications (FAT AP Mode)
| Wireless Capabilities | - SSID broadcast: support
- Number of SSIDs: 7 (2.4GHz) + 7 (5GHz)
- Network type: guest network, employee network
- Wireless encryption: WPA, WPA2, WPA3, WPA-PSK, WPA2-PSK
- User isolation: isolation between wireless networks and isolation within APs
- VLAN settings: support SSID and Tag VLAN binding
- Transmit power setting: support 1dBm linear adjustment
- Wireless client quantity limit: Supported
- QoS: WMM
- Kick out weak signal devices, prohibit weak signal devices from accessing: Supported
|
| Maximum number of associated clients | - 256 (2.4GHz) + 256 (5GHz)
|
| System Management | - Equipment management: full Chinese WEB management
- System log: support
- Restore factory settings: Support
- Backup configuration: Supported
- Import configuration: Supported
- Software upgrade: support
- Ping : support
|
