Tp-Link WIFI6 AX1500 Dual Band Gigabit Port Access Point

In stock

SKU

TL-XAP1502GI

₹8,850.00 ₹7,500.00

Quick Overview

AX1500 Dual-Band Gigabit Wi-Fi 6 Wireless Panel AP

Next-generation Wi-Fi 6 (802.11ax) technology
2.4G/5G dual-band concurrent, wireless rate up to 1500Mbps
National standard 86 ultra-thin shell, beautiful and elegant
802.3af/at standard PoE cable power supply, no external power supply required
Supports TP-LINK Easy Extension function. Simply press a button to enable wireless access to TP-LINK Easy Extension devices
Spectrum navigation guides dual-band clients to connect to 5GHz first, making the load of 2.4GHz and 5GHz bands more balanced and ensuring network performance
FIT mode supports automatic RF tuning
FIT mode supports smart roaming
Support weak signal rejection and prohibition of weak signal device access
Fat and thin in one, different modes can be selected according to different application environments
Supports centralized management of TP-LINK commercial network cloud platform
Support TP-LINK Business Cloud APP remote viewing/management
Machine size (mm): 86*86*33, wall thickness 8mm

Hardware specifications

Installation	Directly installed in the national standard 86 network wiring dark box
size	868633mm
Wireless rate	2.4GHz: 300Mbps 5GHz: 1201Mbps
port	Front: 1 10/100M/1000M RJ45 port Back: 1 10/100M/1000M RJ45 port
antenna	Internal antenna
Indicator Lights	1 system indicator light
Button	1 FAT/FIT mode toggle switch 1 Reset button 1 easy-to-expand button
power supply	Standard PoE power supply
Power consumption	PoE power supply maximum power consumption 9.5W PoE power supply standby power consumption 3.45W
manage	FIT AP mode: managed by TP-LINK wireless controller (AC) FAT AP mode: independent web page management
Usage Environment	Working temperature: 0℃～40℃ Working humidity: 10%～90%RH non-condensing Storage temperature: -40℃～70℃ Storage humidity: 5%~90%RH non-condensing

Wireless Capabilities	SSID broadcast: support Number of SSIDs: 7 (2.4G) + 7 (5G) (supports Chinese SSID) Network type: guest network, employee network Wireless encryption: WPA, WPA2, WPA-PSK, WPA2-PSK, WPA3 User isolation: isolation between wireless networks and isolation within APs Wireless MAC address filtering: support whitelist VLAN settings: support SSID and Tag VLAN binding Transmit power setting: support 1dBm linear adjustment WDS function: support Wireless client quantity limit: Supported QoS: WMM Prohibit weak signal devices from accessing: Support Eliminate weak signal devices: Support Support automatic RF tuning Support smart roaming
Maximum number of associated clients	64 (2.4G) + 119 (5G)
System Management	Equipment management: full Chinese WEB management System log: support Restore factory settings: Support Backup configuration: Supported Import configuration: Supported Software upgrade: support
